Terex Manlift Specifications
Terex is a Westport, Connecticut company which specializes in producing in manufacturing construction equipment. machinery like aerial lifts, manlifts and boom lifts. These kinds of machines are designed to facilitate access to areas that are hard to reach, buildings and roofs, large equipment, amongst other things. A manlift, as defined by the U.S. Occupational Safety and Health Administration refers to a power-driven endless belt. This belt moves just in one direction and contains handholds or platforms or steps that are connected to the unit to be able to transport workers from each floor.
TB85
The TB85 man lift by Terex offers a max working height at 91 feet. The platform's max height reaches 85 feet, while the model's maximum width is 8.5 feet. The TB85 has dimensions measuring 9 feet, 1-inch high and 9 inches wide by 36 feet. This particular model offers a reach of seventy feet. The TB85 has a boom angle above horizontal measuring 75 degrees and below horizontal measures at -14 degrees.
Terex TB100
The maximum height of Terex's TB100 man lift is 106 feet and the maximum height of the platform is 100 feet. The TB100 when stowed away, is about 9 feet high by 8.5 feet wide by 8 feet. The unit's maximum width is 8 feet, 1 1/2 inches. The boom angle below horizontal is -14 degrees and above horizontal is 75 degrees. The horizontal reach measures at 67 feet, 4 inches.
TB110
The TB110 has a maximum platform height of 100 feet and the unit's overall maximum working height reaches 116 feet. When stowed, this model is 8 feet wide x 9 feet, 4 inches high. The TB110 offers a horizontal reach of 67 feet and a maximum width of 8 feet. This particular model has a boom angle of 75 degrees above horizontal plus 10 degrees articulating. It measures -105 degrees articulating and below horizontal it is -14 degrees.
